Specification
| Processor | Industrial-Grade Processor |
| Analog Camera Input | 16 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect |
| User Interface | Web; Local GUI |
| IP Camera Input | Up to 32 channels of IPC access 16 IP channels by default + 16 channels (analog channels are converted to IP channels) incoming bandwidth: 128 Mbps, recording bandwidth: 128 Mbps and outgoing bandwidth: 128 Mbps *After IP channels are added beyond the existing channels, the AI Function (IVS, SMD, FACE) will be disabled |
| Operating System | Embedded Linux |
| Camera Input | 1. CVI: 4K@25/30 fps; 6 MP@20 fps; 5 MP@20 fps; 5 MP@25 fps; 4 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps; 720p@50/60 fps.2. TVI: 4K@15 fps; 5 MP@20 fps; 4 MP@25/30 fps; 3 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps.3. AHD: 4K@15 fps; 5 MP@20 fps; 4 MP@25/30 fps; 3 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30fps |
| Two-way Talk | Support (share the same audio input with the first channel) |
| Video Output | 1 HDMI, 1 VGA HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 *Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable |
| Face Attributes | Gender; Age group; Glasses; Expressions; Face mask; Beard |
| Video Compression | H.265+, H.265, H.264 |
| Frame Rate | Main stream: 4K@(1fps-10fps); 6 MP@(1fps-10fps); 5 MP@(1fps-12fps); 4K-N, 4 MP, 3 MP@ (1fps-15fps); 4M-N, 1080p, 720p, 960H, D1,CIF@(1fps–25/30fps); Sub stream: 960H@(1fps– 15fps); D1/CIF@(1 fps– 25/30fps) |
| Encode Strategy | AI Instastream/ Instastream |
| stream Capability | Dual Stream |
| Face Detection Performance of AI by DVR (Number of Channels) | 4 Channels (up to 12 face images/s each channel) |
| Bit Rate | 32 kbps–6144 kbps |
| Audio Input | 1-channel RCA ,16-channel BNC (Coaxial Audio) |
| Audio Output | 1 Channel RCA |
| Audio Compression | G.711a; G.711u; PCM |
| Audio Sample Rate | 8 kHz, 16 bit |
| Hard Disk | 1 SATA port, up to 8TB capacity for each disk. The maximum HDD capacity varies with environment temperature. |
| Smart Phone | iPhone, iPad, Android Phone |
| Intelligent Alarm | Face detection; Face recognition; Perimeter protection |
| Recording Playback | 1/4/9/16 |
| Browser | Chrome, IE9 or later, Firefox |
| Backup Method | USB device and Network |
| Playback | Instant playback, General playback, Event playback, Tag playback, Smart playback (face and motion detection) |
| Interface Ports | 1 HDMI, 1 VGA, 1 RS485, 2 USB Ports( (1 front USB 2.0 port, 2 rear USB 3.0 port) |
| Network Mode | Single-address mode |
| Ethernet | 1 RJ-45 Port ((10/100/100Mbps) |
| Protocols | HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; ONVIF 22.12(Profile T; Profile S; Profile G); CGI; SDK |
| Power Supply | DC12V, 1Amp |
| Power Consumption | <15W (Without HDD) |
| Operating Temperature | -10 ~+50°C |
| Operating Humidity | 10%–90% (RH) |
| Dimension | 325 mm × 257.1 mm × 55.0 mm |
| Weight | 1.5Kg |
