Specification
| Processor | Industrial-grade embedded processor |
| IP Camera Input | 16 channels |
| Operating System | Embedded LINUX |
| Operation Interface | Web/operating in local GUI |
| Performance by Camera | 8 channel |
| AI Search by Camera | Search for pictures by channel, time and event type |
| Face Attributes | 6 attributes: Gender, age, glasses, expression, mouth mask, and beard |
| AI Search by Face Detection | Search for pictures by channel, time and face attributes |
| Performance by Face Detection | 4 channels |
| Video Output | 1 × VGA output, 1 × HDMI output, supports simultaneous video sources output for VGA and HDMI |
| Compression | Instastream/H.265/Smart H.264+/H.264/MJPEG |
| Performance by SMD Camera | 12 channels |
| AI Search by SMD Camera | Search by target classification (human, vehicle) |
| Network Bandwidth | Access: 160 Mbps; Storage: 160 Mbps; Forward: 64 Mbps |
| Resolution | 8MP; 6MP; 5MP; 4MP; 3MP; 1080p; 720p; D1 |
| Decoding Capability | 8 × 1080p@30fps |
| Multi-screen Display | 1 , 4, 8, 9, 16 views |
| Third-party Camera Access | ONVIF; RTSP |
| General Alarm | Motion detection, privacy masking, video loss, scene changing, PIR alarm, IPC external alarm |
| Anomaly Alarm | Camera disconnection, storage error, disk full, IP conflict, MAC conflict, login locked, and cybersecurity exception |
| Alarm Linkage | Recording, snapshot, audio, buzzer, log, preset, and email |
| Intelligent Alarm | Face detection, perimeter protection (intrusion and tripwire), IVS, people counting, heat map, and SMD alarms |
| Audio Compression | PCM/G711A/G711U/G726/AAC |
| Audio Input | 1 × RCA input |
| Audio Output | 1 × RCA output |
| Alarm Input | 4 Channel |
| Alarm Output | 2 Channel |
| Record Mode | Manual record; alarm recording; SMD recording; smart recording |
| Smart Phone | iPhone, iPad, Android Phone |
| Hard Disk | 2 SATA III ports, up to 10 TB for a single HDD. The maximum HDD capacity varies with environment temperature |
| Browser | Chrome; IE9 or later; firefox |
| Disk Group | Yes |
| Multi-channel Playback | Up to 16 channels for playback |
| Playback Function | Play/pause/stop/slow/quick/backward/by frame Full screen, backup (video clip/file), partial zoom in, and audio on/of |
| Storage | Local HDD; network |
| Backup | USB storage device |
| Interface Ports | 2 USB Ports (1 × front USB2.0; 1 × back USB2.0) |
| Ethernet | 1 × RJ-45, 10/100/1000 Mbps self-adaptive Ethernet port |
| Protocols | HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; IP Search, InstaOn, auto register, ONVIF (profile T/S/G); CGI; SDK |
| Power Supply | 12 V DC, 4 A |
| Power Consumption | < 10 W (HDD not included, idling) |
| Working Temp | -10°C to +55°C (+10 °F to +131 °F) |
| Operating Humidity | 10℅~93℅ |
| Operating Altitude | 3000 m |
| Dimension | 375 mm × 282.4 mm × 53 mm (14.76 |
| Weight | 1.51 kg |
