Specification
| Processor | Industrial-grade processor |
| Operating System | Embedded LINUX |
| IP Camera Input | 4+4 Ch.(analog channels are converted into IP channels) each channel up to 8MP. Incoming bandwidth: 64 Mbps, recording bandwidth: 64 Mbps and outgoing bandwidth: 64 Mbps *After IP channels are added beyond the existing channels, the AI Function (IVS, SMD, FACE) will be disabled. |
| Camera Input | 1. CVI: 4K, 6 MP, 5 MP, 4 MP, 1080p@25/30 fps, 720p@50/60 fps, 720p@25/30 fps. 2. TVI: 4K, 5 MP, 4 MP, 3 MP, 1080p@25/30 fps, 720p@25/30 fps. 3. AHD: 4K, 5 MP, 4 MP, 3 MP, 1080p@25/30 fps, 720p@25/30 fp |
| Analog Camera Input | 4 channels, BNC: adaptive access by default; HDCVI, AHD, TVI and CVBS access can be configured. |
| Two-way Talk | Yes (share the same audio input with the first channel) |
| User Interface | GUI,WEB Interface |
| Perimeter Performance of AI by DVR (Number of Channels) | Advanced Model : 1 channel, 10 IVS for each channel General Model : 4 channels, 10 IVS for each channel |
| Face Detection Performance of AI by DVR (Number of Channels) | 1 channel (up to 8 face images/s) |
| Video Output | 1 HDMI, 1 VGA VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Face Attributes | Gender; age group; glasses; expressions; face mask; beard |
| Face Database Capacity | Up to 10 face databases and 20,000 images. |
| SMD Plus by DVR | 4-channel: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change |
| Face Recognition Performance of AI by DVR (Number of Channels) | 1 ch |
| Compression | H.265; H.264+; H.264 |
| Encode Strategy | AI Instastream, Instastream |
| Encoding Capacity | Main stream: All channel 4K (1 fps–7 fps); 6MP (1 fps– 10 fps); 5MP (1 fps–12 fps); 4K-N, 4MP/3MP (1 fps–15 fps); 4M-N/1080p/720p/960H/D1/CIF (1 fps–25/30 fps); Sub stream: 960H (1 fps–15 fps); D1/CIF (1 fps–25/30 fps) |
| Multi Screen Preview | When IP extension mode not enabled: 1/4 When IP extension mode enabled: 1/4/8/9 |
| Network Mode | Single-address mode |
| Bit Rate | 32 kbps–6144 kbps |
| Audio Input | 1 channel RCA, 4-channel BNC (Coaxial Audio) |
| Audio Output | 1 channel, RCA |
| Audio Compression | G.711a; G.711u; PCM |
| Audio Bit Rate | 64Kbps Per Channel |
| Audio Sample Rate | 8KHz, 16 bit |
| General Alarm | Motion detection, video loss, tampering |
| Anomaly Alarm | No disk, disk error, low space, offline, ip conflict, MAC conflict |
| Intelligent Alarm | Face detection, face recognition, perimeter protection |
| Alarm Linkage | Record, snapshot (panoramic), IPC external alarm output, access controller, voice prompt, buzzer, log, preset, email |
| Smart Phone | iPhone, iPad, Android Phone |
| Hard Disk | 1 SATA port, up to 16TB.(The maximum HDD capacity varies with environment temperature.) |
| Recording Playback | 1/4 |
| Recording Mode | General, motion detection; intelligent; alarm; POS |
| Browser | Chrome, IE9 or later, Firefox |
| Playback | Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection) |
| Backup Mode | USB Device/ Network |
| Interface Ports | 1 HDMI, 1 VGA, 2 USB Ports(2.0), 1 RS485 |
| Ethernet | 1 RJ-45 port (10/100Mbps) |
| Protocols | HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS, ONVIF 21.06, CGI Conformant, InstaOn |
| Power Supply | DC12V/2A |
| Power Consumption | <7W |
| Working Temp | -10 °C to +55 °C (+14 °F to +131 °F) |
| Working Humidity | 0%–90% (RH) |
| Dimension | 325.0 mm × 257.2 mm × 55.0 mm (W × D × H) |
| Weight | 1.16 kg |
